ResNet残差模块

---

import tensorflow as tf

定义ResNetBlock

class ResNetBlock(tf.keras.layers.Layer):
    def __init__(self,units):
        super(ResNetBlock,self).__init__()
        self.conv1 = tf.keras.layers.Conv2D(units,
                                           kernel_size=3,
                                           padding='same',
                                           use_bias=False)
        self.bn1 = tf.keras.layers.BatchNormalization()#批标准化

        self.conv2 = tf.keras.layers.Conv2D(units,
                                           kernel_size=3,
                                           padding='same',
                                           use_bias=False)
        self.bn2 = tf.keras.layers.BatchNormalization()#批标准化

        def call(self,x):
            shortcut = x
            out = self.conv1(x)
            out = tf.nn.relu(self.bn1(out))
            out = self.conv2(out)
            out = tf.nn.relu(self.bn2(out))
            out += shortcut
            return tf.nn.relu(out)

创建ResNetBlock对象

resnet_block = ResNetBlock(64)

加载预训练模型ResNet50

resnet50 = tf.keras.applications.ResNet50(include_top=False,
                                          weights='imagenet',
                                          input_shape=(256,256,3))

==结构绘图==

tf.keras.utils.plot_model(resnet50)

·在anaconda

– conda install graphviz

– conda install pydotplus

·pip

– pip install graphviz

– pip install pydotplus

– pip install pydot
